DIODE DISTORTION

DIST is a very simple diode distortion module with two selectable distortion circuits. You are free to experiment and install the diode pairs of your choice for different flavours of distortion.

Based on the MXR distortion+ / Hexinverter Batteryacid v1.0

Technical Specs

CURRENT DRAW:

  • +12V:   18mA
  • -12V:   0mA
  • +5V:    0mA

DIMENSIONS:

  • WIDTH:   4HP
  • DEPTH:   20mm

BUILD DIFFICULTY: VERY EASY

  • difficulty
    SMD beginner friendly
  • difficulty
    Low part count
